1010 Music Bitbox MK2

Bitbox is a 26HP Eurorack module that delivers recording, clip launching, and looping in a musically intelligent way. With a 24-bit audio path, you can capture and play samples with impeccable audio quality. With clock and MIDI inputs, you can create loops pre-cut to bars or beats and launch clips with similar synchronization. Bitbox has a capacitive touch screen that makes easy work of tweaking, browsing, and loading sounds from your microSD card.

Product Description

• Playback of up to 16 simultaneous samples from internal memory or up to 4 samples directly from microSD

• Trigger samples with the touch screen, CV gate inputs, or MIDI input

• Import or export WAV files with your Mac or PC using a microSD card

• 24-bit 48kHz stereo input and 4-channel output

• Make recordings up to 4 hours in length

• Various launch modes, including one-shot, toggle, gate, and repeat

• Playback can be immediate or synchronized to analog or MIDI clock

• Control of various sample parameters, including start position, length, pitch, gain, loop mode, and launch quantization

• Stereo or mono recording with the option to synchronize the start and stop times to clock inputs

• Save and recall up to 12 different banks of samples and their configuration

• 4 modulation inputs each capable of launching an entire row of clips at once or modulating sample start, length, or pitch

• Export your sets to Ableton Live

• Accepts TRS MIDI input compatible with Arturia and other products

• 26 HP

• +12V: 350mA

• -12V: 0mA

• 5V: 0mA

Say hello to bitbox. Bitbox delivers recording, clip launching, and looping in a musically intelligent way. With a 24-bit audio path, you can capture and play samples with impeccable audio quality. With clock and MIDI inputs, you can create loops pre-cut to bars or beats and launch clips with similar synchronization. Bitbox has a capacitive touch screen that makes easy work of tweaking, browsing, and loading sounds from microSD card.

Features:

Technical Specifications:
